Curtain-side Semi-trailers
1. Structural features of curtain-side semi-trailers
Large load capacity: Curtain-side semi-trailers have a variety of models, which can be selected according to different needs, and the maximum load can reach about 60 tons.
Adjustable height: The height of the curtain-side semi-trailer can be adjusted according to the height of the goods to meet the transportation needs of goods of different heights.
Smooth canvas: When the curtain-side semi-trailer uses canvas, it can avoid friction between the goods and the curtain-side, protecting the goods from damage.
High efficiency: When the curtain-side semi-trailer loads and unloads goods, there is no need to remove the curtain-side, which can greatly improve the loading and unloading efficiency.
2. Scope of application and advantages
Wide scope of application: Curtain-side semi-trailers are suitable for short-distance or medium-distance cargo transportation, and can transport goods of various shapes and specifications.
High reliability: Curtain-side semi-trailers have a simple structure, do not require excessive maintenance, and have high operating reliability.
Economical and practical: Compared with closed semi-trailers, curtain-side semi-trailers are inexpensive and have relatively low maintenance costs, which are suitable for small businesses and individuals.
Technical specifications
Curb weight |
7200kg |
Overall size |
14000*2550*4000mm |
Main frame |
"I" type main frame, height400mm, material Q345B/T700 |
Axle |
BPW/FUWA Brand |
Suspension |
Air suspension |
Tire |
385/65R22.5 |
Side curtain material |
High quality waterproof tape |
Braking syetem |
WABCO |
Bottem plate |
Bamboo plywood |
Side frame |
External upper frame G-type 3.0# bent aluminum track |
Front bezel |
Activity |
